• Single Phase 6 Pole Double Inlet Centrifugal Blower With 9inch Diameter Blade
  • Single Phase 6 Pole Double Inlet Centrifugal Blower With 9inch Diameter Blade
  • Single Phase 6 Pole Double Inlet Centrifugal Blower With 9inch Diameter Blade
  • Single Phase 6 Pole Double Inlet Centrifugal Blower With 9inch Diameter Blade
  • Single Phase 6 Pole Double Inlet Centrifugal Blower With 9inch Diameter Blade
Single Phase 6 Pole Double Inlet Centrifugal Blower With 9inch Diameter Blade

Single Phase 6 Pole Double Inlet Centrifugal Blower With 9inch Diameter Blade

Product Details:

Place of Origin: Shanghai China
Brand Name: Schniro Fan
Certification: CCC ,CE, RoHS, UL
Model Number: RDFA9/7E6

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Packaging Details: Carton,Plywood wooden cases
Delivery Time: 30 work days
Payment Terms: T/T
Get Best Price Contact Now

Detail Information

Blade Material: Galvanized Plate Blade Diameters: 9 Inch
Max Air Flow: 1700 M3/h Max Static Pressure: 180 Pa
Power: 0.31kw Voltage Range: 3~230V +/-10%
Rotate Speed: 800rpm Ambient Temperature: 40°C
Protection Class: IP54 Frequency: 50Hz
High Light:

6 Pole double inlet centrifugal blower

,

Single Phase external rotor motor fan

,

0.31kw double inlet centrifugal blower

Product Description

single phase 6 pole External rotor motor blower with 9inch Diameter blade





Optimal motor cooling and a compact design achieved through the voltage controllable external rotor motor. This product series are high efficiency, a low noise level with a high increase in static pressure.

Impeller diameter range:200-280 mm(7-12 inch). Motor can be applied in different frequency and voltage.



Single Phase 6 Pole Double Inlet Centrifugal Blower With 9inch Diameter Blade 0Single Phase 6 Pole Double Inlet Centrifugal Blower With 9inch Diameter Blade 1



Service is the extension of quality,With outstanding quality and loyal service to pursue the most satisfaction of customers.

Pre-sale Services:
· To provide users with pre-sales technical support, and provide users with a personalized selection or design recommendations based on the actual site's needs.
· User jointly develop applied to industry-specific special purpose machinery.

Sale of services:
· In accordance with the order or user requirements, coordination of stocking or production cycle.
· Provide a detailed production schedule or project plan to the user.

After-sale Service:
· To provide a lifetime goods services for all fans, included equipment maintenance, spare parts supply, provide manuals and video,etc.
· To provide remote service support by phone and network freely.
